增速磨削电主轴
产品型号：PS-JG-1-TR1
技术参数：
1.-Asynchronous motor 2 poles | 异步电机2极 |
2.-Max power 1.2Kw | 最大功率1.2Kw |
3.-Max torque 0.3Nm | 最大扭矩0.3Nm |
4.-Tension 220V | 电压220V |
5.-Max current 4.8A | 最大电流4.8A |
6.- Max speed 40000rpm | 最大转速40000rpm |
7.-N°1 Ø20 front hybrid ceramic bearing | 前端Ø20陶瓷轴承1组 |
8.-Bearings's lubrication by permanent grease | 轴承永久性脂润滑 |
9.-Manual clamping tools | 手动刀具装夹 |
10.-Autonomous cooling | 主轴自动单向冷却 |
11.-Weight Kg 5 | 重量5Kg |
产品特点：
1. 配合U-TRONIC D’ ANDREA,通过手动或电动控制，可实现Ф2-Ф300的圆孔加工。
It is a range of accessories of high precision to grind holes fromФ2-Ф300 and more if they are used together with platform U-TRONIC D’ANDREA
2. 一般工况下，风扇冷却。Autonomous cooling by internal fan.
3. 永久性脂润滑。最低工作时间6000小时。Hybrid ceramic bearings greased by permanent grease without any kind of maintenance for a life of about 6000 working hours.
4. 砂轮选装方式及增速可由数控系统中安装的变频器控制。The grindstone’s speed is controlled in changeable and progressive mode by an apposite frequency electric converter with microprocessor.
5. 每件主轴均配有砂轮延长杆及圆形接口的砂轮杆 all the grinding heads are equipped with apposite wheel holder extensions for normal grindstones and with collects for grindstones with cylindrical attachment.
6. 主轴关键零部件配置采用欧洲著名品牌的ATE电机、L+B编码器、SNFA陶瓷球轴承、OTT旋转接头、balluff传感器。the main parts using famous brand in europe ATE motor, SNFA ceramic ball bearings, Balluff sensor
7. 可选采用HSK、ISO7:24刀柄形式。Tool holder HSK、ISO7:24
8. 可用于金属材料和非金属材料的高速高效加工。an use on the metals and non-metallic material high speed machining.
9. 弹性套夹持刀具，精度高，适用范围广。Tool holder by Collects, high accuracy, fit for different machining.
产品图纸：
