机械主轴
产品型号：PS-M-164-140
技术参数：
1.-Speed max 10000 Rpm | 最大转速10000rpm |
2.-N°3 Ø65 front hybrid ceramic bearing | 前端Ø65陶瓷轴承3组 |
3.-Bearings's lubrication by permanent grease | 轴承永久性脂润滑 |
4.-Internal cooling by liquid circuit | 内部液体冷却 |
5.-Double effect tool’s release hydraulic | 双作用油缸液压松夹 |
6.-Sensor to check the tool change operation | 传感器刀具转换检测 |
7.-Front spindle and rotary joint (option) pressurization | 主轴前端及旋转接头（选项）气密封 |
8.-Tool’s lubrorefrigeration through the centre by rotary joint and arbor’s air cleaning | 旋转接头中心出水刀具冷却及空气涤清 |
产品特点：
1. 主要用于铣削、钻孔和磨削等操作。Mainly used for milling, drilling and grinding and other operations.
2. 可用于金属材料和非金属材料的高速高效加工。Can be used for high-speed and efficient processing of metal and nonmetal materials.
3. 双作用油缸液压松夹Double acting hydraulic cylinder clamping
4. 可选采用HSK、ISO7:24刀柄形式。Tool holder HSK、ISO7:24
5. 具有中心水冷通道，能实现长刀冷却功能。central water channel, can realize long cooling function.
6. 具有锥孔吹气功能，实现主轴换刀过程中的刀柄及锥孔的清洁。Tool cleaning
主轴前端具有刀具外冷环喷功能。Adjustable nozzle
7. 前端3组陶瓷轴承，可提高刚性。N°3 front hybrid ceramic bearing
8. 轴承永久性脂润滑，免维护。Bearings's lubrication by permanent grease
9. 可根据客户需求定制包括自动换刀系统、刀具旋转传感器、旋转接头中心出水及前端气密等。according to customer demand can be used Automatic tool changing system, tool rotation sensor, rotary joint,coolant through spindle and front-side pressurization etc.
产品图纸：
